Technical Specifications |
| Camera: |
| Smooth motorized pan |
| Tilt and zoom |
| Controlled from remote or console 260°pan |
| 130-degree tilt |
| 10x lossless HD zoom |
| 90-degree field of view |
| Full HD 1080p 30fps |
| H.264 UVC 1.5 with Scalable Video Coding (SVC) |
| Autofocus 5 camera presets |
| Far-end control (PTZ) of ConferenceCam product |
| ZEISS lens certification |
| Kensington security slot |
| LED to confirm video streaming |
| Standard tripod thread |
| Remote control: |
| Dockable 8.5 m/28-foot range |
| Speakerphone: |
| Full-duplex performance |
| Acoustic echo cancellation |
| Noise reduction technology |
| Ultra-wideband audio |
| Bluetooth and NFC enabled |
| LCD for caller ID, call duration and other functional response |
| LEDs for speakerphone streaming, mute, hold, and Bluetooth |
| Touch controls for call answer/end, volume and mute, Bluetooth – plus camera |
| PTZ, “home” preset and far-end control |
| Microphones (Tx) |
| Four omni-directional microphones supporting 20-foot/6m diameter range |
| Frequency response: 100Hz – 11KHz |
| Sensitivity: -28dB +/-3dB |
| Distortion: <5% from 200Hz |
| Kensington security slot |
| Hub / Cable: |
| Central mountable hub for connection of all components |
| Included adhesive solution for under-table mounting |
| Two cables for connection between hub and camera/ speakerphone (Length: 5m/16 ft) |
| One USB cable for connection to PC/Mac (Length: 2 m/6.6 ft) |
| AC Power adapter (Length: 3 m/9.8 ft) |
| Mount: |
| Dual purpose mount for wall placement or for elevating camera on table |
| Compliance and tools: |
| USB 2.0 compliant |
| UVC-compliant video and audio for broad application compatibility |
| Skype for Busines certified, Microsoft® Lync®, Cisco Jabber® and WebEx® compatible |
| Enhanced integration with Logitech Collaboration Program (LCP) members |
| Downloadable diagnostic tool |
| Field upgradeable firmware tool |
| Downloadable app plug-ins for advanced feature support |
|
Dimensions |
| Camera: |
| Height x Width x Depth: 5.12 in (130 mm) x 7.0 in (170 mm) x 5.40 in (138 mm) |
| Weight: 1.31lb (585 g) |
| Speakerphone: |
| Height x Width x Depth: 9.5 in (240 mm ) x 2.5 in (65 mm ) x 9.5 in (240 mm ) |
| Weight: 2.68 lb (1223 g) |
| Hub: |
| Height x Width x Depth: 3.75 in (94 mm) x 1.3 in (34 mm) x 2.9 in (74 mm) |
| Weight: 3.0 oz (83 g) |
| Remote: |
| Height x Width x Depth: 2.0 in (50 mm) x 5.0 in(120 mm) x 0.5 in (12 mm) |
| Weight: 2.0 oz (51 g) |
| Wall/Table Mount: |
| Height x Width x Depth: 8.27 in (210 mm) x 4.72 in (120 mm) x 3.9 in (99 mm) |
| Weight: 8.99 oz (255 g) |
| Expansion Mics: |
| Height x Width x Depth: 3.30 in (83 mm) x 3.30 in (83 mm) x 0.83 in (21 mm) |
| Weight: 8.0 oz 230 g) |
| System Requirements |
| Windows® 7, 8.1 or 10 |
| Mac® OS X 10.7 or higher |
| Package Contents |
| Camera |
| Speakerphone |
| Remote control |
| Two 5m/16.4’ cables for connection between speakerphone and hub and camera and hub |
| One 3m/9.8’ meter cable between hub and PC |
| Velcro for cable management |
| Velcro for hub to table securing |
| Powered hub |
| Power adapter with regional plugs |
| Mount |
| Quick start guide |
| Warranty card |
| Warranty Information |
| 2-Year Limited Hardware Warranty |
| Part Number |
| GROUP |
| PN 960-001054 |
| GROUP + Expansion Mics |
| PN 960-001060 |
